 Concept solution for swimming pools

 Monitoring carbonate hardness in a swimming pool's water cycle

The measurement of water hardness in swimming pools. Reduces the cost of maintenance.

Our instrument for  monitoring carbonate hardness in swimming pools:

1 Monitoring carbonate hardness Testomat ECO® C
2 Hardness increase sodium bicarbonate
3 Swimming pool
4 Gushing water container
5 Heat exchangers
6 Filters

The effect of a too low acid capacity on the water treatment facility and water quality is often underestimated.
Low acid capacity makes it difficult for the pH value in the swimming pool water to stabilize. The pH value in turn effects the filtration effect and therefore the disinfecting potential.

Acid capacity also strongly influences the occurrence of corrosion in parts of the facility that are in contact with water. The water is more aggressive the lower the acid capacity is. This leads to corrosion on metal components such as pump drives and fiber backstops, untreated concrete water tanks and on gaps between tiles.

DIN 19643 recommends a weekly inspection of acid capacity in order to be able to permanently control the water quality and the state of the surfaces that are in contact with water. It also recommends a maximum lower limit value of 0.3 mmol for the acid capacity in Jacuzzis and 0.7 mmol in swimmer's pools. In our experience, the ideal value is between 1.5 and 2.0 mmol.

Through online analysis with the Testomat® ECO C, the acid capacity can be stabilized automatically. An exact analysis through titration/quick testing should be conducted at least once a week. For this purpose, we have developed the titration measuring equipment DUROVAL® KS4,3. Its accuracy is 0-0.2 mmol/l for a resolution of 0.05 mmol/l.
